| Outlet Diameter | 106 mm (4.17 inch) |
|---|---|
| Body Diameter Maximum | 197 mm (7.76 inch) |
| Body Length | 655 mm (25.79 inch) |
| Rated Flow LR | 9.4 m³/min (332 cfm) |
| Rated Flow MR | 14 m³/min (494 cfm) |
| Rated Flow HR | 16 m³/min (565 cfm) |
| Restriction LR | 152 mm H2O (5.98 inch H2O) |
| Restriction MR | 203 mm H2O (7.99 inch H2O) |
| Restriction HR | 254 mm H2O (10.00 inch H2O) |
